SANWA SERVO PGS-CX II

PGS-CX II



【Coreless Servo】
●SSL Compatible
※Compatible with CODE10 (M12S (RS), Exzes ZZ, MT-44)
　Not compatible with CODE5 (M12, Exzes Z, MT-4S, MT-4, MT-S)
● MULTI SETTING GEAR compatible
※Not compatible with PGS SETTING GEAR
●SSR mode compatible
●SHR mode compatible
●Lipo 2 cell battery compatible
●High torque type
●Coreless motor
●Metal Gears
●AL Heat Sink
●Waterproof (Same as IPX4)



●Programmable Servo to be compatible with SSL & Telemetry
●Setting Adjustment by wireless from Radio
●Setting Adjustment to connect Servo with Multi Setting Gear
●Regarding Temperature, Current, Voltage and Volume Position on Servo inside,
Telemetry-transmission can be passed to Radio.
# Initial Setting on Multi Setting Gear is necessary.

★Setting Items
●SSL-CH (SSL Channel Setting) ●STRETC (Stretcher Adjustment) ●BOOST (BOOST Adjustment)
●D-Band (Dead Band Adjustment) ●MV-MID (Middle Torque Adjustment)
●MV-END (Later Torque Adjustment) ●BREAK (Break Adjustment)
◎MV-HOLD (Power Adjustment at whole area) ◎MV-FRQ (Feeling Adjustment at whole area)
◎MAX-PW (MAX Duty Adjustment)
※ Multi Setting Gear is necessary for ◎setting.
