ROC HOBBY 1/18 KATANA RTR SCALE CRAWLER W/HARD BODY

ROC HOBBY 1/18 KATANA RTR SCALE CRAWLER W/HARD BODY

From the period-correct lights and functioning indicators to vents on the vehicle body, the Katana was designed to static-model standards. Even the interior is painstakingly recreated in 1:18 scale. A feature-packed trail-proven chassis drives the Katana. Aluminum rails provide a rigid platform whilea multilink geometry with panhard bar chassis design allows for maximum axle articulation.

Power is delivered from the super high-torque gearbox to ultra grippy beadlock tires via nylon driveshafts. Water-resistant 2S 7.4V electronics consists of an independent servo, 2-in-1 receiver/ESC, 050 motor and 7.4V 600mAh battery; Allowing for high power-to-weight ratio and all weather operations.

FEATURES

• Injection-molded hard body
• Functional hood
• Scale interior features
• Multifunctional light control system ( CH3 for on/off and functional indicators)
• Rhino bumper kit & roof rack
• High traction M/T tire with 1.0 inch internal bead lock wheel
• Realistic pinion & ring gear axle
• High torque transmission with 104:1 FDL
• Water resistant electronics with 2.4GHz radio
• High torque over-sized 55T brushed motor
• 7.4v 2S lipo battery with up to 30 minute run time
• Chassis mounted servo
• Aluminum ladder chassis
• Tuned coil shocks

SPECIFICATION

Length: 281.5 mm
Width: 114 mm
Heigth: 137 mm
Wheelbase: 155 mm
Ground clearance: 34 mm
Departure angle: 58,5°
Approach angle: 44 °
Tires: Diameter 66 mm

INCLUDES

• RocHobby 1/18 Katana Scaler RTR Car Kit (1 set)
• Radio System
• USB Charger
• Battery

REQUIRES

• Batteries for transnitter



DECLARATION OF CONFORMITY

ROC003RTR Declaration of Conformity
